Cadenza Black is optimized for an amazing tonal neutrality, dynamics and purity of sound.

The Cadenza Black model is using a Nude Shibata stylus with a boron cantilever. The effective mass of the stylus/cantilever system is extremely low due to the use of a very thin boron rod. This material is extremely stiff and even more lightweight than aluminium.
It also uses the WRD/Wide Range Damping-system applied for MC Windfeld, MC A90, MC Anna, Xpression and MC A95 cartridges, controlling the high and low frequency damping separately.
The coil wire is the famous Ortofon Aucurum wire, which is a gold plated 6NX copper wire.

Cadenza Black is high performing on areas like detail, consistency and sound staging.

More on the Cadenza Series

Ortofon are on the loook out for new technology to be used in their products and push the performance of existing technology. As a result it’s they strive for the highest level of performance and quality. The Kontrapunkt models and MC Jubilee became market standards and are among our most popular cartridges. Nevertheless Ortofon decided to develope a new cartridge series that is even more ambitious.

By carefully implementing cobalt-iron pole pieces, new improved winding process on the armature, using extruded aluminium housing in the models as well as other changes, they have been able to reveal new possibilities in performing the analogue information. It was also decided to make a more complete range of cartridges, which meant an introduction of a moving coil Cadenza Mono model to support our customers, who have an extended interest in micro groove mono records.

Specifications

Output voltage at 1000 Hz, 5cm/sec. – 0,33 mV
Channel balance at 1 kHz – < 0,8 dB
Channel separation at 1 kHz – > 27 dB
Channel separation at 15 kHz – > 20 dB
Frequency range at – 3dB – 20 – 60.000 Hz
Frequency response 20 kHz – 20 kHz – +1,5/0
Tracking ability at 315Hz at recommended tracking force *) – 90 µm
Compliance, dynamic, lateral – 16 µm/mN
Stylus type – Nude Shibata on Boron cantilever
Stylus tip radius – r/R 6/50 µm
Tracking force range – 2,0-2,5 g (20-25 mN)
Tracking force, recommended – 2,3 g (23 mN)
*) Typical value

Tracking angle – 20°
Internal impedance, DC resistance – 5 Ohm
Recommended load impedance – > 10 Ohm
Cartridge body material – Stainless steel Aluminium
Cartridge colour – Black/Black
Cartridge weight – 10,7 gram
