The NAD PP2e Phono Pre-amplifier offers superb performance in a clean and simple package for a very reasonable cost. Perfect for the budget-conscious audiophile, the PP 2e’s moving coil/moving magnet input selector provides different phono cartridge options. Our PP 2e is incredibly easy-to-use and is certain to bring years of enjoyment to any lover of vinyl LPs. The PP 2e’s Auto Power Down feature saves energy by automatically powering the PP 2e to OFF when not in use.

Technical specifications

• MC
  Input Impedance (R and C) > 100Ω + 180pF
  Gain at 1kHz > 60dB
  Input sensitivity (ref. 200mV ouput) 0.3mV
  Signal to noise (A  weighted, with cartridge connected) 78dB
  Input overload (20Hz/1kHz/20kHz) >  0.8/9/84mV
  Rated Distortion (THD 20Hz – 20kHz) <0.03%
  RIAA response accuracy > ±0.3dB Infrasonic filter 10Hz -3dB
  Digital output (USB) > 16 bit linear PCM
  Sampling frequency > 48kHz
  Dynamic range > 86dB
• MM
  Input Impedance (R and C) > 47kΩ + 200pF Gain at 1kHz
  Input sensitivity (ref. 200mV ouput) 5mV 2.5mV
  Signal to noise (A weighted, with cartridge connected) 80dB
  Input overload (20Hz/1kHz/20kHz)
  10/100/900mV 10/102/950mV
  Rated Distortion (THD 20Hz – 20kHz) <0.03%
  RIAA response accuracy ±0.3dB
  Dimensions excl. Power supply (W x H x D) 135 x 49 x 72mm
  Output Impedance 100Ω
