Marantz LINK 10n Reference-class Network Audio Player The BEST of the BEST

From the triple-layer aluminum chassis with copper plating to entirely original multi-layer PCBs, isolated sub-enclosures and HDAM modules, LINK 10n is the product of decades of expertise in audio engineering. It sets a new benchmark with meticulous construction, state-of-the art technologies, and elegant design.

Sound Master Tuned

As the flagship digital player in the Marantz portfolio, LINK 10n features the best measured performance of any digital product we’ve ever produced. Through extensive and careful listening, the Sound Master has selected numerous premium parts to be included in key circuits that elevate audible performance to a new standard of excellence.

Intuitive Display

LINK 10n comes with a large high-resolution full-color display for a beautiful user interface and intuitive operation. Familiar arrow buttons make navigation effortless. Scroll to select your desired input and see source, track info, and play mode displayed on the screen, or enjoy easy HEOS onboarding and access to the app via a QR code.

Marantz Industrial Design

Machined and brushed aluminum control surface, sculpted backshell, spun knobs, and high-resolution full color display are each striking features of 10 Series components. The design is both distinctively Marantz, drawing inspiration from classic models, and progressively modern.

Preamplifier Function

LINK 10n can act as a complete preamplifier front-end for your system, with all the functions of a modern high-end stereo system. Complete with single ended and balanced analog inputs, digital inputs, and a Marantz Premium Phono EQ supporting both MM and MC cartridges, it is also a fully featured front end for even the highest performance stereo systems.

Key Technologies

Specifications

The detailed specifications for the Marantz LINK 10n Reference-class Network Audio Player are listed below.

General

• Unit (W × H × D mm) 440 × 192 × 472 (with antenna)
• Cabinet Size 440 × 192 × 422
• Net weight 33.3kg
• Packaging Dimensions (W × H × D mm) 600 × 379 × 540
• Packaging gross weight 38.7g
• Carton Color 1 Color (Material color: Brown Printing: Black)
• Panel Color Black / Marantz Champagne
• Front (Center) Pane Aluminum
• Back-shell Aluminum
• Front panel illumination Yes (All sides, Dimmer)
• Side cover Aluminum (Thickness: Max 15.8mm)
• Top cover (Centor) ventilation hole material No
• Interior illumination No
• Rear Panel Triple layer Copper-plated
• Chassis Material Copper-plated
• Bottom Layer / Bottom plate Copper-plated
• Volume Knob Solid aluminum (Bearing construction)
• Input Selector Solid aluminum (Bearing construction)
• Foot Solid aluminum with Copper


  ---

Audio

• Frequency Response PCM 2Hz–50kHz (-3dB)
• Harmonic distortion PCM 0.0004%
• S/N PCM 0.0004%
• Dynamic range PCM 0.0004%
• Line Output Leve UNBALANCED: 2.0Vrms
  BALANCED: 4.0Vrms
• Headphone Output Level 130mW / 32 ohms
• Frequency Response (analog input) 5 Hz–100 kHz (+0dB/-3 dB)
• Harmonic distortion (analog input) 0.001% (20Hz–20kHz)
• S/NPHONO (MC): 76dB
  HONO (MM): 88dB
  BALANCED: 122dB
  LINE: 122dB
• Phono Input sensitivity MM: 8mV
  MC: 80mV
• Phono Input impedance MC Low: 32 ohms
  MC Mid: 100 ohms
  MC High: 390 ohms
  MM: 39 kohms
• Power Consumption 7W
  Less than 0.3W (at Standby)
  Less than 2W (at Network Control On: Bluetooth, Ethernet, Wi-Fi, USB)

  ---

Audio Feature

• Output Circuit New HDAM
• Power Transformer Toroidal
• Pre-Amplifier Circuit New HDAM High Grade
  Full balance
• Volume Electric (MUSES 72323)
  Variable gain
• Bass / Treble / Mid / Balance Control | Yes / Yes / No / Yes
• Type of Tone Control Electric
• Headphone Circuit Discrete
• H/P Amp Gain Setting Yes (Low / Mid / High)
• H/P On. Off Setting H/P Off automatically, when in use
• DAC Circuit New MMM-Conversion
• Dither MMM-Stream
  (Dither 1, 2, Off)
• Noise Shaper MMM-Stream
  Balanced, Natural, Dynamic Music, Dynamic Voice)
• Digital Filter MMM-Stream
  Filter 1, 2 Selectable
• Jitter Reducer Yes
• DAC Master Clock Design (No Support for Network Playback) Yes
• Asynchronous mode (for USB-B input) Yes
• Isolator (for USB-B input) Yes (Complete Isolation System Duo)
• Fixed Analog Output (RCA) Cinch × 1
  Thick nickel-plated independent terminals
• Pre / Variable Audio Output (RCA)Cinch × 1
  Thick nickel-plated independent terminals
• Fixed Balanced XLR Output Yes (1 Pair)
• Pre/ Variable Balanced XLR Output Yes (1 Pair)
• RCA Input Cinch × 1
  Thick nickel-plated independent terminals
• Balanced XLR Input Yes (1 Pair)
• Phono input Yes (MM / MC)
  Marantz Musical Premium Phono EQ w/ Selectable MC impedance (3 position)
  Thick nickel-plated independent terminals
• Optical input / output (Maximum Support) 2 / 1 (on/off switchable)
  44.1 kHz – 192 kHz
• Coaxial input / output (Maximum Support) 1 / 1 (on/off switchable)
  44.1 kHz – 192 kHz
• HDMI input / output No / Yes (ARC)
• Headphone Output Yes (Φ6.3 ×1)
• Subwoofer Yes with LP filter adjustable


  ---

Easy to use

• App HEOS app
• Remote Controller 10 series universal Remote control
• Front Panel Display New HD TFT Color Display
• Display Language | (English/ German/ French/ Italian/ Dutch/ Spanish/ Swedish/ Polish/ Russian)
  U: (English/ French/ Spanish)
  K: ( Simplified Chinese/English)
  F: (Japanese/ English)
• Dimmer for Front Display 20 steps
• Level meter No
• Volume Display 0 –100 / 0.5 step (default)-infinity/-99.5dB – 0dB / 0.5 step switchable
• Voice Assistant Apple Siri
  Google Assistant
• Control with App via Network Player (Use Remote Control Bus) No
• External Amp Control with App (Use Remote Control Bus) Yes
• Synchronously turn on amplifier and switch the input (Use Remote Control Bus) Yes
• HDMI CEC Yes
• Remote Controller RC004PMND
• Battery Yes (AAA ×2)
• Power Cord Yes (ALL region: Audio Grade: OFC)
• Other Stereo RCA Cable ×1
  Remote connector cable ×1
  CoA card
